TMZ Performance

                           DSM Throttle Bodies



TMZ Performance Rebuilds DSM Throttle Bodies Too!
  • If you are experiencing idle surge, boost leaks, RPMs ramping up or down, or are unable to control your idle due to worn out gaskets, seals or BISS screw, you are in need of a throttle body rebuild.
  • Send us your throttle body for a full service rebuild!  Be sure to include your sensors with the throttle body, and they will be tested for no extra charge!  Prices include priority mail shipping to U.S. addresses via USPS.
  • We Specialize in rebuliding all 4G63 DSM throttle bodies including:
      • 1990 Non-Turbo
      • 1990 Turbo
      • 1991-1994 Non-Turbo
      • 1991-1994 Turbo
      • 1995-1999 Turbo


Each throttle body rebuild consists of the following steps and new parts:
  • The throttle body is fully disassembled and degreased.
  • The bare throttle body parts are then bead blasted using plastic or glass bead media to prevent etching of the throttle body shaft or bore.
  • The bore is precision cleaned and inspected.
  • The shaft is precision cleaned and inspected.
  • New heavy-duty high-pressure shaft seals are installed.
  • New Base Idle Set Screw (BISS), BISS O-ring and BISS screw cap installed.
  • New Fast Idle Air Valve (FIAV) waffle gasket installed.
  • FIAV fully disassembled and degreased.
  • FIAV blockoff plate installed with new Hex-Cap high-capacity black-oxide finish Stainless Steel fasteners (optional upgrade for $24.00).
  • New Idle Speed Controller (ISC) O-ring.
  • Test all included sensors per factory specifications, and install any sensors supplied.
  • Include New Mitsubishi OEM inner and outer throttle body gaskets.
Throttle Body Rebuild Pricing:
***Includes Labor, Parts, and Return Shipping -- You will need to ship your core throttle body in for these services!***
  • 1990 Throttle Bodies -- $115.00



  • 1991-1994 Throttle Bodies -- $110.00



  • 1995-1999 Throttle Bodies -- $110.00
  • FIAV Block-Off Plate and Hex-Cap high-capacity black-oxide finish Stainless Steel fasteners  $24.00
TMZ Performance currently has limited core throttle bodies in-stock.
We currently have core throttle bodies for the following models:
  • 1990 Turbo
  • 1995-1999 Turbo
All other models would require the customer to ship in their throttle body for rebuild services.

Please contact us at tmzperformance@gmail.com with any questions you may have about our services!
